Non-Dimmable

Filter
    19 products

    19 products

    HV9650S - 10w 12v DC Weatherproof LED Driver
    • Weatherproof LED driver
    • Flex and plug included
    • IP rating: IP66
    • Input voltage: 240v AC
    • Output voltage: 12v DC
    • Output power: 10w
    • Recommended Maximum Load: 8w
    • Minimum Load: 1w
    • 3 years replacement warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 315-316

    Data Sheet

    HV9651 - 20w 12v Weatherproof LED Driver
    • Weatherproof LED driver
    • Flex and plug included
    • IP rating: IP66
    • Input voltage: 240v AC
    • Output voltage: 12v DC
    • Output power: 20w
    • Recommended maximum load: 16w
    • Minimum Load: 2w
    • 3 years replacement warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 315

    Data Sheet

    Installation Instructions

    HV9652 - 30w Weatherproof LED Driver
    • Weatherproof LED Driver
    • Flex and Plug Included
    • IP rating: IP66
    • Input Voltage: 240v AC
    • Output Power: 30w
    • Recommended maximum load: 24w
    • Minimum Load: 3w
    • 3 Years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 315-316
    Part Number Output Voltage
    HV9652 12v DC Constant Voltage
    HV9652-24V 24v DC Constant Voltage

    Data Sheet

    Installation Instructions

    HV9653 - 60w Weatherproof LED Driver
    • Weatherproof LED Driver
    • Flex and Plug Included
    • IP rating: IP66
    • Input Voltage: 240v AC
    • Output Power: 60w
    • Recommended maximum load: 48w
    • Minimum Load: 6w
    • 3 Years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 315-316
    Part Number Output Voltage
    HV9653 12v DC Constant Voltage
    HV9653-24V 24v DC Constant Voltage

    Data Sheet

    Installation Instructions

    HV9654 - 100w Weatherproof LED Driver
    • Weatherproof LED Driver
    • Flex and Plug Included
    • IP rating: IP66
    • Input Voltage: 240v AC
    • Output Power: 100w
    • Recommended maximum load: 80w
    • Minimum Load: 10w
    • 3 years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 315-316
    Part Number Output Voltage
    HV9654 12v DC Constant Voltage
    HV9654-24V 24v DC Constant Voltage

    Data Sheet

    Installation Instructions

    HV9658-30W - 30w Weatherproof LED Driver
    • Weatherproof LED Driver
    • High Power Factor
    • Flex and Plug Included
    • IP rating: IP66
    • Input Voltage: 240v AC
    • Output Power: 30w
    • Recommended maximum load: 24w
    • Minimum Load: 3w
    • 3 Years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 315-316
    Part Number  Output Voltage
    HV9658-12V30W 12v DC Constant Voltage
    HV9658-24V30W 24v DC Constant Voltage

    Data Sheet

    Installation Instructions

    HV9658-60W - 60w Weatherproof LED Driver
    • Weatherproof LED Driver
    • High Power Factor
    • Flex and Plug Included
    • IP rating: IP66
    • Input Voltage: 240v AC
    • Output Power: 60w
    • Recommended maximum load: 48w
    • Minimum Load: 6w
    • 3 Years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 315-316
    Part Number Output Voltage
    HV9658-12V60W 12v DC Constant Voltage
    HV9658-24V60W 24v DC Constant Voltage

    Data Sheet

    Installation Instructions

    HV9658-60WS - 60w Slimline Weatherproof LED Driver
    • Slimline Weatherproof LED Driver
    • Flex and Plug Included
    • IP rating: IP66
    • Input Voltage: 240v AC
    • Available in Both 12v DC or 24v DC
    • Output Power: 60w
    • Recommended maximum load: 48w
    • Minimum Load: 6w
    • 3 Years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 315-316
    Part Number Output Voltage
    HV9658-12V60WS 12v DC Constant Voltage
    HV9658-24V60WS 24v DC Constant Voltage

    Data Sheet

    Installation Instructions

    HV9658-95WS - 95w Slimline Weatherproof LED Driver
    • Slimline Weatherproof LED Driver
    • Flex and Plug Included
    • IP rating: IP66
    • Input Voltage: 240v AC
    • Available in Both 12v DC or 24v DC
    • Output Power: 95w
    • Recommended maximum load: 80w
    • Minimum Load: 9w
    • 3 Years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 315-316
    Part Number Output Voltage
    HV9658-12V95WS 12v DC
    HV9658-24V95WS 24v DC

    Data Sheet

    Installation Instructions

    HV9658-100W - 100w Weatherproof LED Driver
    • Weatherproof LED Driver
    • High Power Factor
    • Flex and plug included
    • IP rating: IP66
    • Input Voltage: 240v AC
    • Output Power: 100w
    • Recommended maximum load: 80w
    • Minimum Load: 10w
    • 3 years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 315-316
    Part Number Output Voltage
    HV9658-12V100W 12v DC Constant Voltage
    HV9658-24V100W 24v DC Constant Voltage

    Data Sheet

    Installation Instructions

    HV9658-150W - 150w Weatherproof LED Driver
    • Weatherproof LED Driver
    • High Power Factor
    • Flex and plug included
    • IP rating: IP66
    • Input Voltage: 240v AC
    • Output Power: 150w
    • Recommended maximum load: 120w
    • Minimum Load: 15w
    • 3 Years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 315-316
    Part Number Output Voltage
    HV9658-12V150W 12v DC Constant Voltage
    HV9658-24V150W 24v DC Constant Voltage

    Data Sheet

    Installation Instructions

    HV9658-200W - 200w Weatherproof LED Driver
    • Weatherproof LED Driver
    • High Power Factor
    • Flex and Plug Included
    • IP rating: IP66
    • Input Voltage: 240v AC
    • Output Power: 200w (2 x 100w )
    • Recommended maximum load: 160w
    • Minimum Load: 20w
    • 3 Years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 315-316
    Part Number Output Voltage
    HV9658-12V200W 12v DC Constant Voltage
    HV9658-24V200W 24v DC Constant Voltage

    Data Sheet

    Installation Instructions

    HV9658-12V275W - 275w Weatherproof LED Driver
    • Weatherproof LED Driver
    • High Power Factor
    • Flex and Plug Included
    • IP rating: IP66
    • Input Voltage: 240v AC
    • Output Voltage: 12v DC Constant Voltage
    • Output Power: 275w (2 x 137.5w)
    • Recommended maximum load: 240w
    • Minimum Load: 27w
    • 3 Years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 315-316

    Data Sheet

    Installation Instructions

    HV9658-24V300W - 300w Weatherproof LED Driver
    • Weatherproof LED driver
    • High power factor
    • Flex and plug included
    • IP rating: IP66
    • Input voltage: 240v AC
    • Output Voltage: 24v DC
    • Output power: 300w (2 x 150w)
    • Recommended maximum load: 240w
    • Minimum Load: 30w
    • 3 Years replacement warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 316

    Data Sheet

    Installation Instructions

    HV9665-12V4W / HV9665-24V4W - 4w IP65 Weatherproof LED Driver
    • Weatherproof LED Driver
    • IP Rating: IP65
    • Input Voltage: 240v AC
    • Output Voltage: 12v or 24v DC constant voltage
    • Output Power: 4w
    • Recommended maximum load: 3w
    • Minimum Load: 0.4w
    • 3 Years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 323-324
     Part Number Output Voltage
    HV9665-12V4W 12v DC
    HV9665-24V4W 24v DC

    Data Sheet

    HV9666-20W - 20w Indoor LED Driver
    • Indoor LED Driver
    • Flex and Plug Included
    • IP rating: IP20
    • Input Voltage: 240v AC
    • Output Voltage: 12v or 24v DC Constant Voltage
    • Output Power: 20w
    • Recommended maximum load: 16w
    • Minimum Load: 2w
    • 3 Years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 323-324
     Part Number Output Voltage
    HV9666-12V20W 12v DC Constant Voltage
    HV9666-24V20W 24v DC Constant Voltage

    Data Sheet

    Installation Instructions

    HV9666-30W - 30w Indoor LED Driver
    • Indoor LED Driver
    • Flex and Plug Included
    • IP rating: IP20
    • Input Voltage: 240v AC
    • Output Voltage: 12v or 24v DC Constant Voltage
    • Output Power: 30w
    • Recommended maximum load: 24w
    • Minimum Load: 3w
    • 3 Years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 323-324
     Part Number Output Voltage
    HV9666-12V30W 12v DC Constant Voltage
    HV9666-24V30W 24v DC Constant Voltage

    Data Sheet

    Installation Instructions

    HV9667-60W - 60w Indoor LED Driver
    • Indoor LED Driver
    • Flex and Plug Included
    • IP rating: IP20
    • Input Voltage: 240v AC
    • Output Voltage: 12v or 24v DC
    • Output Power: 60w
    • Recommended maximum load: 48w
    • Minimum Load: 6w
    • 3 Years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 323-324
     Part Number Output Voltage
    HV9667-12V60W 12v DC Constant Voltage
    HV9667-24V60W 24v DC Constant Voltage

    Data Sheet

    Installation Instructions

    HV9667-75W - 75w Indoor LED Driver
    • Indoor LED Driver
    • Flex and Plug Included
    • IP rating: IP20
    • Input Voltage: 240v AC
    • Output Voltage: 12v or 24v DC
    • Output Power: 75w
    • Recommended maximum load: 60w
    • Minimum Load: 7w
    • 3 Years Replacement Warranty (items ordered after 01/01/22)
    • 2022 Catalogue Pages 323-324
     Part Number Output Voltage
    HV9667-12V75W 12v DC Constant Voltage
    HV9667-24V75W 24v DC Constant Voltage

    Data Sheet

    Installation Instructions
