Outdoor Wall Lights

153 products

153 products

  • Tivah Up & Down Wall Pillar Light
  • Stainless Steel 316 Marine Grade
  • Matching Backing Plate
  • High Output Reflector To Maximise Light
  • TRI Colour
  • 3000k, 4000k + 5500k
  • IP Rating: IP65
  • Beam Angle (HV1005): 60 degrees
  • Beam Angle (HV1007): 120 degrees
  • Input Voltage: 240v AC or 12v DC
  • 2 Years Replacement Warranty
  • 12v model must be used with suitable 12v DC LED driver
  • 2021 Catalogue Page 1
 Part Number Colour Temp Lumens Included LED
HV1005T

3000k

4000k

5500k

2x 200-560lm

2x 255-595lm

2x 270-630lm

2x 3/5/7w

240v

GU10

HV1007GU10T

3000k

4000k

5500k

2x 270lm

2x 285lm

2x 300lm

2x 5w

240v

GU10

HV1007MR16T

3000k

4000k

5500k

2x 270lm

2x 285lm

2x 300lm

2x 5w

12v DC

MR16

Data Sheet

Download

IES Files

Download

Installation Instructions

Download



    • Tivah Up & Down Wall Pillar Light
    • Solid Copper
    • Includes Matching Backing Plate
    • High Output Reflector To Maximise Light
    • TRI Colour
    • 3000k, 4000k + 5500k
    • IP Rating: IP65
    • Beam Angle (HV1015): 60 degrees
    • Beam Angle (HV1017): 120 degrees
    • Input Voltage: 240v AC or 12v DC
    • 2 Years Replacement Warranty
    • 2021 Catalogue Page 3

    12v model must be used with suitable 12v DC LED driver

     Part Number Colour Temp Lumens Included LED
    HV1015T

    3000k

    4000k

    5500k

    2x 200-560lm

    2x 255-595lm

    2x 270-630lm

    2x 3/5/7w

    240v

    GU10

    HV1017GU10T

    3000k

    4000k

    5500k

    2x 270lm

    2x 285lm

    2x 300lm

    2x 5w

    240v

    GU10

    HV1017MR16T

    3000k

    4000k

    5500k

    2x 270lm

    2x 285lm

    2x 300lm

    2x 5w

    12v DC

    MR16

    Data Sheet

    Download

    IES Files

    Download HV1015

    Download HV1017

    Installation Instructions

    Download



      • Tivah Up & Down Wall Pillar Light
      • Aluminium Poly Powder Coated Black
      • Includes Matching Backing Plate
      • High Output Reflector To Maximise Light
      • TRI Colour
      • 3000k, 4000k + 5500k
      • IP Rating: IP65
      • Beam Angle (HV1025): 60 degrees
      • Beam Angle (HV1027): 120 degrees
      • Input Voltage: 240v AC or 12v DC
      • 2 Years Replacement Warranty
      • 2021 Catalogue Page 5

      12v model must be used with suitable 12v DC LED driver

       Part Number Colour Temp Lumens Included LED
      HV1025T

      3000k

      4000k

      5500k

      2x 200-560lm

      2x 255-595lm

      2x 270-630lm

      2x 3/5/7w

      240v

      GU10

      HV1027GU10T

      3000k

      4000k

      5500k

      2x 270lm

      2x 285lm

      2x 300lm

      2x 5w

      240v

      GU10

      HV1027MR16T

      3000k

      4000k

      5500k

      2x 270lm

      2x 285lm

      2x 300lm

      2x 5w

      12v DC

      MR16

      Data Sheet

      Download

      IES Files

      Download 1025

      Download 1027

      Installation Instructions

      Download



        • Tivah Up & Down Wall Pillar Light
        • Aluminium Poly Powder Coated White
        • Includes Matching Backing Plate
        • High Output Reflector To Maximise Light
        • TRI Colour
        • 3000k, 4000k + 5500k
        • IP Rating: IP65
        • Beam Angle (HV1035): 60 degrees
        • Beam Angle (HV1037): 120 degrees
        • Input Voltage: 240v AC or 12v DC
        • 2 Years Replacement Warranty
        • 2021 Catalogue Page 7

        12v model must be used with suitable 12v DC LED driver

         Part Number Colour Temp Lumens Included LED
        HV1035T

        3000k

        4000k

        5500k

        2x 200-560lm

        2x 255-595lm

        2x 270-630lm

        2x 3/5/7w

        240v

        GU10

        HV1037GU10T

        3000k

        4000k

        5500k

        2x 270lm

        2x 285lm

        2x 300lm

        2x 5w

        240v

        GU10

        HV1037MR16T

        3000k

        4000k

        5500k

        2x 270lm

        2x 285lm

        2x 300lm

        2x 5w

        12v DC

        MR16

        Data Sheet

        Download

        IES Files

        Download 1035

        Download 1037

        Installation Instructions



        Download
            • Tivah Up & Down Wall Pillar Light
            • Aluminium Poly Powder Coated Silver
            • Includes Matching Backing Plate
            • High Output Reflector To Maximise Light
            • TRI Colour
            • 3000k, 4000k + 5500k
            • IP Rating: IP65
            • Beam Angle (HV1045): 60 degrees
            • Beam Angle (HV1047): 120 degrees
            • Input Voltage: 240v AC or 12v DC
            • 2 Years Replacement Warranty
            • 2021 Catalogue Page 9

            12v model must be used with suitable 12v DC LED driver

             Part Number Colour Temp Lumens Included LED
            HV1045T

            3000k

            4000k

            5500k

            2x 200-560lm

            2x 255-595lm

            2x 270-630lm

            2x 3/5/7w

            240v

            GU10

            HV1047GU10T

            3000k

            4000k

            5500k

            2x 270lm

            2x 285lm

            2x 300lm

            2x 5w

            240v

            GU10

            HV1047MR16T

            3000k

            4000k

            5500k

            2x 270lm

            2x 285lm

            2x 300lm

            2x 5w

            12v DC

            MR16

            Data Sheet

            Download

            IES Files

            Download 1045

            Download 1047

            Installation Instructions



            Download
              • Piaz Up & Down Wall Pillar Light
              • High Grade 304 Stainless Steel
              • TRI Colour
              • 3000k, 4000k + 5500k
              • IP Rating: IP54
              • Beam Angle: 120 degrees
              • Input Voltage: 240v AC
              • 2 Years Replacement Warranty
              • 2021 Catalogue Page 15
               Part Number Colour Temp Lumens Included LED
              HV1071T

              3000k

              4000k

              5500k

              2x 270lm

              2x 285lm

              2x 300lm

              2x 5w GU10

                Data Sheet

                Download

                Installation Instructions

                Download

                IES Files

                Download 1071

                • Fortis Up & Down Wall Pillar Light
                • High Grade 304 Stainless Steel
                • TRI Colour
                • 3000k, 4000k + 5500k
                • IP Rating: IP54
                • Beam Angle: 120 degrees
                • Input Voltage: 240v AC
                • 2 Years Replacement Warranty
                • 2021 Catalogue Page 17
                 Part Number Colour Temp Lumens Included LED
                HV1072T

                3000k

                4000k

                5500k

                2x 270lm

                2x 285lm

                2x 300lm

                2x 5w GU10

                  Data Sheet

                  Download

                  Installation Instructions

                  Download

                  • Tivah Up & Down Wall Pillar Light
                  • Titanium Coloured Aluminium
                  • Includes Matching Backing Plate
                  • High Output Reflector To Maximise Light
                  • TRI Colour
                  • 3000k, 4000k + 5500k
                  • IP Rating: IP65
                  • Input Voltage: 240v AC or 12v DC
                  • 2 Years Replacement Warranty
                  • 2021 Catalogue Page 11

                  12v model must be used with suitable 12v DC LED driver

                   Part Number Colour Temp Lumens Included LED
                  HV1085T

                  3000k

                  4000k

                  5500k

                  2x 200-560lm

                  2x 255-595lm

                  2x 270-630lm

                  2x 3/5/7w

                  240v

                  GU10

                  HV1087GU10T

                  3000k

                  4000k

                  5500k

                  2x 270lm

                  2x 285lm

                  2x 300lm

                  2x 5w

                  240v

                  GU10

                  HV1087MR16T

                  3000k

                  4000k

                  5500k

                  2x 270lm

                  2x 285lm

                  2x 300lm

                  2x 5w

                  12v DC

                  MR16

                    Data Sheet

                    Download

                    IES Files

                    Download 1085

                    Download 1087

                    Installation Instructions

                    Download

                    • Highlite Up & Down Wall Pillar Light
                    • Aluminium Poly Powder Coated Black
                    • Matching Backing Plate
                    • High-Grade Perspex Reflector Lens
                    • TRI Colour
                    • IP rating: IP65
                    • Beam Angle: 120 degrees
                    • Input Voltage: 240v AC
                    • 2x 5w GU10 LED
                    • 2 Years Replacement Warranty
                    • 2021 Catalogue Page 16

                    Must be used with LED Globes only.

                    Part number Colour Temp Lumens
                    HV1089T-BLK-240V

                    3000k

                    4000k

                    5500k

                    2x 270lm

                    2x 285lm

                    2x 300lm

                    Data Sheet

                    Download

                    Installation Instructions

                    Download

                    • Highlite Up & Down Wall Pillar Light
                    • Titanium Coloured Aluminium
                    • Matching Backing Plate
                    • High-Grade Perspex Reflector Lens
                    • TRI Colour
                    • IP rating: IP65
                    • Beam Angle: 120 degrees
                    • Input Voltage: 240v AC
                    • 2x 5w GU10 LED
                    • 2 Years Replacement Warranty
                    • 2021 Catalogue Page 16

                    Must be used with LED Globes only.

                    Part number Colour Temp Lumens
                    HV1089T-TTM-240V

                    3000k

                    4000k

                    5500k

                    2x 270lm

                    2x 285lm

                    2x 300lm

                    Data Sheet

                    Download

                    Installation Instructions

                    Download



                    • Tivah Up & Down Wall Pillar Light
                    • Solid Brass with Antique Brass Finish
                    • Includes Matching Backing Plate
                    • High Output Reflector To Maximise Light
                    • TRI Colour
                    • 3000k, 4000k + 5500k
                    • IP Rating: IP65
                    • Input Voltage: 240v AC or 12v DC
                    • 2 Years Replacement Warranty
                    • 2021 Catalogue Page 13

                    12v model must be used with suitable 12v DC LED driver

                     Part Number Colour Temp Lumens Included LED
                    HV1095T

                    3000k

                    4000k

                    5500k

                    2x 200-560lm

                    2x 255-595lm

                    2x 270-630lm

                    2x 3/5/7w

                    240v

                    GU10

                    HV1097GU10T

                    3000k

                    4000k

                    5500k

                    2x 270lm

                    2x 285lm

                    2x 300lm

                    2x 5w

                    240v

                    GU10

                    HV1097MR16T

                    3000k

                    4000k

                    5500k

                    2x 270lm

                    2x 285lm

                    2x 300lm

                    2x 5w

                    12v DC

                    MR16

                    Data Sheet

                    Download

                    IES Files

                    Download 1095

                    Download 1097

                    Installation Instructions

                    Download

                      • Tivah Fixed Down Wall Pillar Light
                      • Stainless Steel 316 Marine Grade
                      • Matching Backing Plate
                      • High Output Reflector To Maximise Light
                      • TRI Colour
                      • 3000k, 4000k + 5500k
                      • IP Rating: IP65
                      • Input Voltage: 240v AC or 12v DC
                      • 2 Years Replacement Warranty
                      • 2021 Catalogue Page 1

                      12v model must be used with suitable 12v DC LED driver

                       Part Number Colour Temp Lumens Included LED
                      HV1105T

                      3000k

                      4000k

                      5500k

                      200-560lm

                      255-595lm

                      270-630lm

                      3/5/7w

                      240v

                      GU10

                      HV1107GU10T

                      3000k

                      4000k

                      5500k

                      270lm

                      285lm

                      300lm

                      5w

                      240v

                      GU10

                      HV1107MR16T

                      3000k

                      4000k

                      5500k

                      270lm

                      285lm

                      300lm

                      5w

                      12v DC

                      MR16

                        Data Sheet

                        Download

                        IES Files

                        Download 1105

                        Download 1107

                        Installation Instructions

                        Download

                        • Mini Tivah Fixed Down Wall Pillar Light
                        • Stainless Steel 316 Marine Grade
                        • Matching Backing Plate
                        • High Output Reflector To Maximise Light
                        • 3000k, 4000k
                        • IP Rating: IP65
                        • Input Voltage: 12v DC
                        • 2 Years Replacement Warranty
                        • 2021 Catalogue Page 19

                        Must be used with a suitable 12v DC LED driver

                         Part Number Colour Temp Lumens Included LED
                        HV1107MR11NW

                        3000k

                        4000k

                        270lm

                        300lm

                         3w 3000k MR11 LED

                        3w 4000k MR11 LED

                          Data Sheet

                          Download

                          Installation Instructions

                          Download

                          • Tivah Fixed Down Wall Pillar Light
                          • Solid Copper
                          • Matching Backing Plate
                          • High Output Reflector To Maximise Light
                          • TRI Colour
                          • 3000k, 4000k + 5500k
                          • IP Rating: IP65
                          • Input Voltage: 240v AC or 12v DC
                          • 2 Years Replacement Warranty
                          • 2021 Catalogue Page 3

                          12v model must be used with suitable 12v DC LED driver

                           Part Number Colour Temp Lumens Included LED
                          HV1115T

                          3000k

                          4000k

                          5500k

                          200-560lm

                          255-595lm

                          270-630lm

                          3/5/7w

                          240v

                          GU10

                          HV1117GU10T

                          3000k

                          4000k

                          5500k

                          270lm

                          285lm

                          300lm

                          5w

                          240v

                          GU10

                          HV1117MR16T

                          3000k

                          4000k

                          5500k

                          270lm

                          285lm

                          300lm

                          5w

                          12v DC

                          MR16

                            Data Sheet

                            Download

                            IES Files

                            Download 1115

                            Download 1117

                            Installation Instructions

                            Download



                            • Tivah Fixed Down Wall Pillar Light
                            • Aluminium Poly Powder Coated Black
                            • Matching Backing Plate
                            • High Output Reflector To Maximise Light
                            • TRI Colour
                            • 3000k, 4000k + 5500k
                            • IP Rating: IP65
                            • Input Voltage: 240v AC or 12v DC
                            • 2 Years Replacement Warranty
                            • 2021 Catalogue Page 5

                            12v model must be used with suitable 12v DC LED driver

                            Part Number Colour Temp Lumens Included LED
                            HV1125T

                            3000k

                            4000k

                            5500k

                            200-560lm

                            255-595lm

                            270-630lm

                            3/5/7w

                            240v

                            GU10

                            HV1127GU10T

                            3000k

                            4000k

                            5500k

                            270lm

                            285lm

                            300lm

                            5w

                            240v

                            GU10

                            HV1127MR16T

                            3000k

                            4000k

                            5500k

                            270lm

                            285lm

                            300lm

                            5w

                            12v DC

                            MR16

                              Data Sheet

                              Download

                              IES Files

                              Download 1125

                              Download 1127

                              Installation Instructions

                              Download

                              • Mini Tivah Fixed Down Wall Pillar Light
                              • Aluminium Poly Powder Coated Black
                              • Matching Backing Plate
                              • High Output Reflector To Maximise Light
                              • 3000k, 4000k
                              • IP Rating: IP65
                              • Input Voltage: 12v DC
                              • 2 Years Replacement Warranty
                              • 2021 Catalogue Page 21

                              Must be used with a suitable 12v DC LED driver

                              Part Number Colour Temp Lumens Included LED
                              HV1127MR11NW

                              3000k

                              4000k

                               270lm

                              300lm

                               3w 3000k MR11 LED

                              3w 4000k MR11 LED

                                Data Sheet

                                Download

                                Installation Instructions

                                Download

                                • Tivah Fixed Down Wall Pillar Light
                                • Aluminium Poly Powder Coated White
                                • Matching Backing Plate
                                • High Output Reflector To Maximise Light
                                • TRI Colour
                                • 3000k, 4000k + 5500k
                                • IP Rating: IP65
                                • Input Voltage: 240v AC or 12v DC
                                • 2 Years Replacement Warranty
                                • 2021 Catalogue Page 7

                                12v model must be used with suitable 12v DC LED driver

                                Part Number Colour Temp Lumens Included LED
                                HV1135T

                                3000k

                                4000k

                                5500k

                                200-560lm

                                255-595lm

                                270-630lm

                                3/5/7w

                                240v

                                GU10

                                HV1137GU10T

                                3000k

                                4000k

                                5500k

                                270lm

                                285lm

                                300lm

                                5w

                                240v

                                GU10

                                HV1137MR16T

                                3000k

                                4000k

                                5500k

                                270lm

                                285lm

                                300lm

                                5w

                                12v DC

                                MR16

                                  Data Sheet

                                  Download

                                  IES Files

                                  Download 1135

                                  Download 1337

                                  Installation Instructions

                                  Download

                                  • Tivah Fixed Down Wall Pillar Light
                                  • Aluminium Poly Powder Coated Silver
                                  • Matching Backing Plate
                                  • High Output Reflector To Maximise Light
                                  • TRI Colour
                                  • 3000k, 4000k + 5500k
                                  • IP Rating: IP65
                                  • Input Voltage: 240v AC or 12v DC
                                  • 2 Years Replacement Warranty
                                  • 2021 Catalogue Page 9

                                  12v model must be used with suitable 12v DC LED driver

                                  Part Number Colour Temp Lumens Included LED
                                  HV1145T

                                  3000k

                                  4000k

                                  5500k

                                  200-560lm

                                  255-595lm

                                  270-630lm

                                  3/5/7w

                                  240v

                                  GU10

                                  HV1147GU10T

                                  3000k

                                  4000k

                                  5500k

                                  270lm

                                  285lm

                                  300lm

                                  5w

                                  240v

                                  GU10

                                  HV1147MR16T

                                  3000k

                                  4000k

                                  5500k

                                  270lm

                                  285lm

                                  300lm

                                  5w

                                  12v DC

                                  MR16

                                    Data Sheet

                                    Download

                                    IES Files

                                    Download 1145

                                    Download 1147

                                    Installation Instructions

                                    Download

                                    • Piaz Fixed Down Wall Pillar Light
                                    • High Grade 304 Stainless Steel
                                    • TRI Colour
                                    • 3000k, 4000k + 5500k
                                    • IP rating: IP54
                                    • Beam Angle: 120 degrees
                                    • Input voltage: 240v AC
                                    • 5w GU10 LED Globe
                                    • 2 Years Replacement Warranty
                                    • 2021 Catalogue Page 15

                                    12v model must be used with suitable 12v DC LED driver

                                    Part Number Colour Temp
                                    Lumens
                                    HV1171T

                                    3000k

                                    4000k

                                    5500k

                                    270lm

                                    285lm

                                    300lm

                                    Data Sheet

                                    Download

                                    Installation Instructions

                                    Download

                                    • Fortis Fixed Down Wall Pillar Light
                                    • High Grade 304 Stainless Steel
                                    • IP rating: IP54
                                    • TRI Colour
                                    • 3000k, 4000k + 5500k
                                    • Beam Angle: 120 degrees
                                    • Input voltage: 240v AC
                                    • 5w GU10 LED Globe
                                    • 2 Years Replacement Warranty
                                    • 2021 Catalogue Page 17
                                    Part Number Colour Temp
                                    Lumens
                                    HV1172T

                                    3000k

                                    4000k

                                    5500k

                                    270lm

                                    285lm

                                    300lm

                                    Data Sheet

                                    Download

                                    Installation Instructions

                                    Download

                                    • Tivah Fixed Down Wall Pillar Light
                                    • Titanium Coloured Aluminium
                                    • Matching Backing Plate
                                    • High Output Reflector To Maximise Light
                                    • TRI Colour
                                    • 3000k, 4000k + 5500k
                                    • IP Rating: IP65
                                    • Input Voltage: 240v AC or 12v DC
                                    • 2 Years Replacement Warranty
                                    • 2021 Catalogue Page 11

                                    12v model must be used with suitable 12v DC LED driver

                                    Part Number Colour Temp Lumens Included LED
                                    HV1185T

                                    3000k

                                    4000k

                                    5500k

                                    200-560lm

                                    255-595lm

                                    270-630lm

                                    3/5/7w

                                    240v

                                    GU10

                                    HV1187GU10T

                                    3000k

                                    4000k

                                    5500k

                                    270lm

                                    285lm

                                    300lm

                                    5w

                                    240v

                                    GU10

                                    HV1187MR16T

                                    3000k

                                    4000k

                                    5500k

                                    270lm

                                    285lm

                                    300lm

                                    5w

                                    12v DC

                                    MR16

                                      Data Sheet

                                      Download

                                      IES Files

                                      Download 1185

                                      Download 1187

                                      Instruction Instructions

                                      Download

                                      • Tivah Fixed Down Wall Pillar Light
                                      • Solid Brass with Antique Brass Finish
                                      • Matching Backing Plate
                                      • High Output Reflector To Maximise Light
                                      • TRI Colour
                                      • 3000k, 4000k + 5500k
                                      • IP Rating: IP65
                                      • Input Voltage: 240v AC or 12v DC
                                      • 2 Years Replacement Warranty
                                      • 2021 Catalogue Page 13

                                      12v model must be used with suitable 12v DC LED driver

                                      Part Number Colour Temp Lumens Included LED
                                      HV1195T

                                      3000k

                                      4000k

                                      5500k

                                      200-560lm

                                      255-595lm

                                      270-630lm

                                      3/5/7w

                                      240v

                                      GU10

                                      HV1197GU10T

                                      3000k

                                      4000k

                                      5500k

                                      270lm

                                      285lm

                                      300lm

                                      5w

                                      240v

                                      GU10

                                      HV1197MR16T

                                      3000k

                                      4000k

                                      5500k

                                      270lm

                                      285lm

                                      300lm

                                      5w

                                      12v DC

                                      MR16

                                        Data Sheet

                                        Download

                                        IES Files

                                        Download 1195

                                        Download 1197

                                        Installation Instructions

                                        Download

                                        • Tivah Single Adjustable Wall Pillar Light
                                        • Stainless Steel 316 Marine Grade
                                        • Matching Backing Plate
                                        • 90° Tilt & 270° Swivel
                                        • High Output Reflector To Maximise Light
                                        • TRI Colour
                                        • 3000k, 4000k + 5500k
                                        • IP Rating: IP65
                                        • Input Voltage: 240v AC or 12v DC
                                        • 2 Years Replacement Warranty
                                        • 2021 Catalogue Page 2

                                        12v model must be used with suitable 12v DC LED driver

                                        Part Number Colour Temp Lumens Included LED
                                        HV1205T

                                        3000k

                                        4000k

                                        5500k

                                        200-560lm

                                        255-595lm

                                        270-630lm

                                        3/5/7w

                                        240v

                                        GU10

                                        HV1207GU10T

                                        3000k

                                        4000k

                                        5500k

                                        270lm

                                        285lm

                                        300lm

                                        5w

                                        240v

                                        GU10

                                        HV1207MR16T

                                        3000k

                                        4000k

                                        5500k

                                        270lm

                                        285lm

                                        300lm

                                        5w

                                        12v DC

                                        MR16

                                          Data Sheet

                                          Download

                                          IES Files

                                          Download 1205

                                          Download 1207

                                          Installation Instructions

                                          Download

                                          • Mini Tivah Single Adjustable Wall Pillar Light
                                          • Stainless Steel 316 Marine Grade
                                          • Matching Backing Plate
                                          • 90° Tilt & 270° Swivel
                                          • High Output Reflector To Maximise Light
                                          • 3000k, 4000k
                                          • IP Rating: IP65
                                          • Input Voltage: 12v DC
                                          • 2 Years Replacement Warranty
                                          • 2021 Catalogue Page 20

                                          12v model must be used with a suitable 12v DC LED driver

                                          Part Number Colour Temp Lumens Included LED
                                          HV1207MR11NW

                                          3000k

                                          4000k

                                          270lm

                                          300lm



                                          3w 3000k MR11 LED

                                          3w 4000k MR11 LED



                                            Data Sheet

                                            Download

                                            Installation Instructions

                                            Download

                                            • Maxi Tivah Single Adjustable Wall Pillar Light
                                            • 316 Stainless Steel
                                            • Matching Backing Plate
                                            • 90° Tilt & 270° Swivel
                                            • High Output Reflector To Maximise Light
                                            • TRI Colour
                                            • 3000k, 4000k + 5500k
                                            • IP Rating: IP65
                                            • Beam Angle: 60 degrees
                                            • Input Voltage: 240v AC
                                            • 2 Years Replacement Warranty
                                            • 2021 Catalogue Page 23-24
                                            Part Number Colour Temp Lumens Included LED
                                            HV1208T

                                            3000k

                                            4000k

                                            5500k

                                            1080lm

                                            1140lm

                                            1200lm

                                             TRI Colour

                                            12w Built in LED

                                              Data Sheet

                                              Download

                                              Installation Instructions

                                              Download

                                              • Tivah Single Adjustable Wall Pillar Light
                                              • Solid Copper
                                              • Matching Backing Plate
                                              • 90° Tilt & 270° Swivel
                                              • High Output Reflector To Maximise Light
                                              • TRI Colour
                                              • 3000k, 4000k + 5500k
                                              • IP Rating: IP65
                                              • Input Voltage: 240v AC or 12v DC
                                              • 2 Years Replacement Warranty
                                              • 2021 Catalogue Page 4

                                              12v model must be used with suitable 12v DC LED driver

                                              Part Number Colour Temp Lumens Included LED
                                              HV1215T

                                              3000k

                                              4000k

                                              5500k

                                              200-560lm

                                              255-595lm

                                              270-630lm

                                              3/5/7w

                                              240v

                                              GU10

                                              HV1217GU10T

                                              3000k

                                              4000k

                                              5500k

                                              270lm

                                              285lm

                                              300lm

                                              5w

                                              240v

                                              GU10

                                              HV1217MR16T

                                              3000k

                                              4000k

                                              5500k

                                              270lm

                                              285lm

                                              300lm

                                              5w

                                              12v DC

                                              MR16

                                                Data Sheet

                                                Download

                                                IES Files

                                                Download 1215

                                                Download 1217

                                                Installation Instructions

                                                Download

                                                • Tivah Single Adjustable Wall Pillar Light
                                                • Aluminium Poly Powder Coated Black
                                                • Matching Backing Plate
                                                • 90° Tilt & 270° Swivel
                                                • High Output Reflector To Maximise Light
                                                • TRI Colour
                                                • 3000k, 4000k + 5500k
                                                • IP Rating: IP65
                                                • Input Voltage: 240v AC or 12v DC
                                                • 2 Years Replacement Warranty
                                                • 2021 Catalogue Page 6

                                                12v model must be used with suitable 12v DC LED driver

                                                Part Number Colour Temp Lumens Included LED
                                                HV1225T

                                                3000k

                                                4000k

                                                5500k

                                                200-560lm

                                                255-595lm

                                                270-630lm

                                                3/5/7w

                                                240v

                                                GU10

                                                HV1227GU10T

                                                3000k

                                                4000k

                                                5500k

                                                270lm

                                                285lm

                                                300lm

                                                5w

                                                240v

                                                GU10

                                                HV1227MR16T

                                                3000k

                                                4000k

                                                5500k

                                                270lm

                                                285lm

                                                300lm

                                                5w

                                                12v DC

                                                MR16

                                                  Data Sheet

                                                  Download

                                                  IES Files

                                                  Download 1225

                                                  Download 1227

                                                  Installation Instructions

                                                  Download

                                                  • Tivah Single Adjustable Wall Pillar Light
                                                  • Aluminium Poly Powder Coated Black
                                                  • Matching Backing Plate
                                                  • 90° Tilt & 270° Swivel
                                                  • High Output Reflector To Maximise Light
                                                  • 3000k, 4000k
                                                  • IP Rating: IP65
                                                  • Input Voltage: 12v DC
                                                  • 2 Years Replacement Warranty
                                                  • 2021 Catalogue Page 22

                                                  Must be used with a suitable 12v DC LED driver

                                                  Part Number Colour Temp Lumens Included LED
                                                  HV1227MR11NW

                                                  3000k

                                                  4000k

                                                  270lm

                                                  300lm

                                                  3w 3000k M11 LED

                                                  3w 4000k MR11 LED

                                                    Data Sheet

                                                    Download

                                                    Installation Instructions

                                                    Download

                                                    • Maxi Tivah Single Adjustable Wall Pillar Light
                                                    • Aluminium Poly Powder Coated Black
                                                    • Matching Backing Plate
                                                    • 90° Tilt & 270° Swivel
                                                    • High Output Reflector To Maximise Light
                                                    • TRI Colour
                                                    • 3000k, 4000k + 5500k
                                                    • IP Rating: IP65
                                                    • Beam Angle: 60 degrees
                                                    • Input Voltage: 240v AC
                                                    • 2 Years Replacement Warranty
                                                    • 2021 Catalogue Page 25-26
                                                    Part Number Colour Temp Lumens Included LED
                                                    HV1228T

                                                    3000k

                                                    4000k

                                                    5500k

                                                    1080lm

                                                    1140lm

                                                    1200lm

                                                     TRI Colour

                                                    12w Built in LED

                                                      Data Sheet

                                                      Download

                                                      Installation Instructions

                                                      Download

                                                      • Tivah Single Adjustable Wall Pillar Light
                                                      • Aluminium Poly Powder Coated White
                                                      • Matching Backing Plate
                                                      • 90° Tilt & 270° Swivel
                                                      • High Output Reflector To Maximise Light
                                                      • TRI Colour
                                                      • 3000k, 4000k + 5500k
                                                      • IP Rating: IP65
                                                      • Beam Angle (HV1237): 120 degrees
                                                      • Beam Angle (HV1235): 60 degrees
                                                      • Input Voltage: 240v AC or 12v DC
                                                      • 2 Years Replacement Warranty
                                                      • 2021 Catalogue Page 8

                                                      12v model must be used with suitable 12v DC LED driver

                                                      Part Number Colour Temp Lumens Included LED
                                                      HV1235T

                                                      3000k

                                                      4000k

                                                      5500k

                                                      200-560lm

                                                      255-595lm

                                                      270-630lm

                                                      3/5/7w

                                                      240v

                                                      GU10

                                                      HV1237GU10T

                                                      3000k

                                                      4000k

                                                      5500k

                                                      270lm

                                                      285lm

                                                      300lm

                                                      5w

                                                      240v

                                                      GU10

                                                      HV1237MR16T

                                                      3000k

                                                      4000k

                                                      5500k

                                                      270lm

                                                      285lm

                                                      300lm

                                                      5w

                                                      12v DC

                                                      MR16

                                                        Data Sheet

                                                        Download

                                                        IES Files

                                                        Download 1235

                                                        Download 12337

                                                        Installation Instructions

                                                        Download

                                                        • Tivah Single Adjustable Wall Pillar Light
                                                        • Aluminium Poly Powder Coated Silver
                                                        • Matching Backing Plate
                                                        • 90° Tilt & 270° Swivel
                                                        • High Output Reflector To Maximise Light
                                                        • TRI Colour
                                                        • 3000k, 4000k + 5500k
                                                        • IP Rating: IP65
                                                        • Beam Angle (HV1247): 60 degrees
                                                        • Beam Angle (HV1245): 120 degrees
                                                        • Input Voltage: 240v AC or 12v DC
                                                        • 2 Years Replacement Warranty
                                                        • 2021 Catalogue Page 10

                                                        12v model must be used with suitable 12v DC LED driver

                                                        Part Number Colour Temp Lumens Included LED
                                                        HV1245T

                                                        3000k

                                                        4000k

                                                        5500k

                                                        200-560lm

                                                        255-595lm

                                                        270-630lm

                                                        3/5/7w

                                                        240v

                                                        GU10

                                                        HV1247GU10T

                                                        3000k

                                                        4000k

                                                        5500k

                                                        270lm

                                                        285lm

                                                        300lm

                                                        5w

                                                        240v

                                                        GU10

                                                        HV1247MR16T

                                                        3000k

                                                        4000k

                                                        5500k

                                                        270lm

                                                        285lm

                                                        300lm

                                                        5w

                                                        12v DC

                                                        MR16

                                                          Data Sheet

                                                          Download

                                                          IES Files

                                                          Download 1245

                                                          Download 1247

                                                          Installation Instructions

                                                          Download

                                                          • Piaz Single Adjustable Wall Pillar Light
                                                          • High Grade 304 Stainless Steel
                                                          • 90° Tilt & 270° Swivel
                                                          • TRI Colour
                                                          • 3000k, 4000k + 5500k
                                                          • IP rating: IP54
                                                          • Beam Angle: 120 degrees
                                                          • Input voltage: 240v AC
                                                          • 5w GU10 LED Globe
                                                          • 2 Years Replacement Warranty
                                                          • 2021 Catalogue Page 15
                                                          Part Number
                                                          Colour Temp
                                                          Lumens
                                                          HV1271T

                                                          3000k

                                                          4000k

                                                          5500k

                                                          270lm

                                                          285lm

                                                          300lm

                                                          Data Sheet

                                                          Download

                                                          Installation Instructions

                                                          Download

                                                          • Fortis Single Adjustable Wall Pillar Light
                                                          • High Grade 304 Stainless Steel
                                                          • 90° Tilt & 270° Swivel
                                                          • TRI Colour
                                                          • 3000k, 4000k + 5500k
                                                          • IP rating: IP54
                                                          • Input voltage: 240v AC
                                                          • 5w GU10 LED Globe
                                                          • 2 Years Replacement Warranty
                                                          • 2021 Catalogue Page 18
                                                          Part Number
                                                          Colour Temp
                                                          Lumens
                                                          HV1272T

                                                          3000k

                                                          4000k

                                                          5500k

                                                          270lm

                                                          285lm

                                                          300lm

                                                          Data Sheet

                                                          Download

                                                          Installation Instructions

                                                          Download

                                                          • Tivah Single Adjustable Wall Pillar Light
                                                          • Titanium Coloured Aluminium
                                                          • Matching Backing Plate
                                                          • 90° Tilt & 270° Swivel
                                                          • High Output Reflector To Maximise Light
                                                          • TRI Colour
                                                          • 3000k, 4000k + 5500k
                                                          • IP Rating: IP65
                                                          • Input Voltage: 240v AC or 12v DC
                                                          • 2 Years Replacement Warranty
                                                          • 2021 Catalogue Page 12

                                                          12v model must be used with suitable 12v DC LED driver

                                                          Part Number Colour Temp Lumens Included LED
                                                          HV1285T

                                                          3000k

                                                          4000k

                                                          5500k

                                                          200-560lm

                                                          255-595lm

                                                          270-630lm

                                                          3/5/7w

                                                          240v

                                                          GU10

                                                          HV1287GU10T

                                                          3000k

                                                          4000k

                                                          5500k

                                                          270lm

                                                          285lm

                                                          300lm

                                                          5w

                                                          240v

                                                          GU10

                                                          HV1287MR16T

                                                          3000k

                                                          4000k

                                                          5500k

                                                          270lm

                                                          285lm

                                                          300lm

                                                          5w

                                                          12v DC

                                                          MR16

                                                            Data Sheet

                                                            Download

                                                            IES Files

                                                            Download 1285

                                                            Download 1287

                                                            Installation Instructions

                                                            Download

                                                            • Tivah Single Adjustable Wall Pillar Light
                                                            • Solid Brass with Antique Brass Finish
                                                            • Matching Backing Plate
                                                            • 90° Tilt & 270° Swivel
                                                            • High Output Reflector To Maximise Light
                                                            • TRI Colour
                                                            • 3000k, 4000k + 5500k
                                                            • IP Rating: IP65
                                                            • Input Voltage: 240v AC or 12v DC
                                                            • 2 Years Replacement Warranty
                                                            • 2021 Catalogue Page 14

                                                            12v model must be used with suitable 12v DC LED driver

                                                            Part Number Colour Temp Lumens Included LED
                                                            HV1295T

                                                            3000k

                                                            4000k

                                                            5500k

                                                            200-560lm

                                                            255-595lm

                                                            270-630lm

                                                            3/5/7w

                                                            240v

                                                            GU10

                                                            HV1297GU10T

                                                            3000k

                                                            4000k

                                                            5500k

                                                            270lm

                                                            285lm

                                                            300lm

                                                            5w

                                                            240v

                                                            GU10

                                                            HV1297MR16T

                                                            3000k

                                                            4000k

                                                            5500k

                                                            270lm

                                                            285lm

                                                            300lm

                                                            5w

                                                            12v DC

                                                            MR16

                                                              Data Sheet

                                                              Download

                                                              IES Files

                                                              Download 1295

                                                              Download 1297

                                                              Installation Instructions

                                                              Download
