HV9690-2618 Compatible LED Strip

89 products

89 products

  • 3000k High Lumen LED strip
  • 3m Double Side Tape For Easy Installation
  • 9.6w Per Metre
  • 128 x 2835 LED Chips Per Metre
  • 1040lm Per Metre
  • CRI>90
  • Size: 8mm x 2mm
  • Cutting Increments: 63mm
  • Input voltage: 24v DC
  • IP rating: IP20
  • Maximum Length:10 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 380

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 4000k High Lumen LED Strip
  • 3m Double Side Tape For Easy Installation
  • 9.6w Per Metre
  • 128 x 2835 LED Chips Per Metre
  • 1140lm Per Metre
  • CRI>90
  • Size: 8mm x 2mm
  • Cutting Increments: 63mm
  • Input voltage: 24v DC
  • IP rating: IP20
  • Maximum Length: 10 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 380

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 5500k High Lumen LED strip
  • 3m Double Side Tape For Easy Installation
  • 9.6w Per Metre
  • 128 x 2835 LED Chips Per Metre
  • 1240lm Per Metre
  • CRI>90
  • Size: 8mm x 2mm
  • Cutting Increments: 63mm
  • Input voltage: 24v DC
  • IP rating: IP20
  • Maximum Length: 10 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 380

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 3000k High Lumen LED Strip
  • 3m Double Side Tape For Easy Installation
  • 4.8w Per Metre
  • 64 x 2835 LED Chips Per Metre
  • 520lm Per Metre
  • CRI>90
  • Size: 8mm x 2mm
  • Cutting Increments: 125mm
  • Input voltage: 24v DC
  • IP rating: IP20
  • Maximum Length: 10 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 380

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 4000k High Lumen LED Strip
  • 3m Double Side Tape For Easy Installation
  • 4.8w Per Metre
  • 64 x 2835 LED Chips Per Metre
  • 570lm Per Metre
  • CRI>90
  • Size: 8mm x 2mm
  • Cutting Increments: 125mm
  • Input voltage: 24v DC
  • IP rating: IP20
  • Maximum Length: 10 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 380

Must Be installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 5500k High Lumen LED Strip
  • 3m Double Side Tape For Easy Installation
  • 4.8w Per Metre
  • 64 x 2835 LED Chips Per Metre
  • 620lm Per Metre
  • CRI>90
  • Size: 8mm x 2mm
  • Cutting Increments: 125mm
  • Input voltage: 24v DC
  • IP rating: IP20
  • Maximum Length: 10 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 380

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 3000k LED Strip
  • 3m Double Side Tape For Easy Installation
  • 9.6w Per Metre
  • 120 x 3528 LED Chips Per Metre
  • 780lm Per Metre
  • Size: 8mm x 2mm
  • Cutting Increments: 25mm
  • Input voltage: 12v DC
  • IP Rating: IP20
  • Maximum Length: 5 Metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 382

Must Be Installed on aluminium heat dissipating surface for warranty purposes.

  • 50m Roll of 3000k LED Strip
  • Supplied With 25 x Ezi Tail Connectors
  • 3m Double Side Tape For Easy Installation
  • 9.6w per metre
  • 120 x 3528 LED Chips Per Metre
  • 780lm Per Metre
  • Size: 8mm x 2mm
  • Cutting Increments: 25mm
  • Input voltage: 12v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 387

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 4000k LED Strip
  • 3m Double Side Tape For Easy Installation
  • 9.6w Per Metre
  • 120 x 3528 LED Chips Per Metre
  • 820lm Per Metre
  • Size: 8mm x 2mm
  • Cutting Increments: 25mm
  • Input voltage: 12v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 384

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 50m Roll of 4000k LED Strip
  • Supplied with 25 x Ezi Tail Connectors
  • 3m Double Side Tape For Easy Installation
  • 9.6w Per Metre
  • 120 x 3528 LED Chips Per Metre
  • 820lm Per Metre
  • Size: 8mm x 2mm
  • Cutting Increments: 25mm
  • Input voltage: 12v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 387

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 5500k LED Strip
  • 3m Double Side Tape For Easy Installation
  • 9.6w Per Metre
  • 120 x 3528 LED Chips Per Metre
  • 860lm Per Metre
  • Size: 8mm x 2mm
  • Cutting Increments: 25mm
  • Input voltage: 12v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Pages 386

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 50m Roll of 5500k LED Strip
  • Supplied With 25 x Ezi Tail Connectors
  • 3m Double Side Tape For Easy Installation
  • 9.6w Per Metre
  • 120 x 3528 LED Chips Per Metre
  • 860lm Per Metre
  • Size: 8mm x 2mm
  • Cutting Increments: 25mm
  • Input voltage: 12v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 387

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 3000k LED Strip
  • 3m Double Sided Tape For Easy Installation
  • 19.2w Per Metre
  • 240 x 3528 LED Chips Per Metre
  • 1560lm Per Metre
  • Size: 10mm x 2mm
  • Cutting Increments: 25mm
  • Input voltage: 24v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 382

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 3000k LED Strip
  • 3m Double Sided Tape For Easy Installation
  • 19.2w Per Metre
  • 240 x 3528 LED Chips Per Metre
  • 1560lm Per Mtre
  • Size: 16mm x 2mm
  • Cutting Increments: 50mm
  • Input voltage: 24v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 382

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 4000k LED Strip
  • 3m Double Sided Tape For Easy Installation
  • 19.2w Per Metre
  • 240 x 3528 LED Chips Per Metre
  • 1640lm Per Metre
  • Size: 10mm x 2mm
  • Cutting Increments: 25mm
  • Input voltage: 24v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 384

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 4000k LED Strip
  • 3m Double Sided Tape For Easy Installation
  • 19.2w Per Metre
  • 240 x 3528 LED Chips Per Metre
  • 1640lm Per Metre
  • Size: 16mm x 2mm
  • Cutting Increments: 50mm
  • Input voltage: 24v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 384

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 5500k LED Strip
  • 3m Double Sided Tape For Easy Installation
  • 19.2w Per Metre
  • 240 x 3528 LED Chips Per Metre
  • 1720lm Per Metre
  • Size: 10mm x 2mm
  • Cutting Increments: 25mm
  • Input voltage: 24v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Pages 386

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 5500k LED Strip
  • 3m Double Sided Tape For Easy Installation
  • 19.2w Per Metre
  • 240 x 3528 LED Chips Per Metre
  • 1720lm Per Metre
  • Size: 16mm x 2mm
  • Cutting Increments: 50mm
  • Input voltage: 24v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Pages 386

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 3000k LED Strip
  • 3m Double Sided Tape For Easy Installation
  • 4.8w Per Metre
  • 60 x 3528 LED Chips Per Metre
  • 390lm Per Metre
  • Size: 8mm x 2mm
  • Cutting Increments: 50mm
  • Input voltage: 12v DC
  • IP rating: IP20
  • Maximum Length: 5 Metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 382

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 50m Roll of 3000k LED Strip
  • Supplied With 25 x Ezi Tail Connectors
  • 3m Double Sided Tape For Easy Installation
  • 4.8w Per Metre
  • 60 x 3528 LED Chips Per Metre
  • 390lm Per Metre
  • Size: 8mm x 2mm
  • Cutting Increments: 50mm
  • Input voltage: 12v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 387

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

Data Sheet

Installation Instructions

IES Files

  • 4000k LED Strip
  • 3m Double Side Tape For Easy Installation
  • 4.8w Per Metre
  • 60 x 3528 LED Chips Per Metre
  • 410lm Per Metre
  • Size: 8mm x 2mm
  • Cutting Increments: 50mm
  • Input voltage: 12v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 384

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 50M roll of 4000k LED Strip
  • Supplied With 25 x Ezi-Tail Connectors
  • 3m Double Sided Tape For Easy Installation
  • 4.8w Per Metre
  • 60 x 3528 LED Chips Per Metre
  • 410lm Per Metre
  • Size: 8mm x 2mm
  • Cutting Increments: 50mm
  • Input voltage: 12v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 387

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 5500k LED Strip
  • 3m Double Sided Tape For Easy Installation
  • 4.8w Per Metre
  • 60 x 3528 LED Chips Per Metre
  • 430lm Per Metre
  • Size: 8mm x 2mm
  • Cutting Increments: 50mm
  • Input voltage: 12v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Pages 386

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 50m Roll of 5500k LED Strip
  • Supplied With 25 x Ezi Tail Connectors
  • 3m Double Sided Tape For Easy Installation
  • 4.8w Per Metre
  • 60 x 3528 LED Chips Per Metre
  • 430lm Per Metre
  • Size: 8mm x 2mm
  • Cutting Increments: 50mm
  • Input volatge: 12v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 2 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 387

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

Data Sheet

IES Files

Installation Instructions

  • Blue LED Strip
  • 3m Double Sided Tape For Easy Installation
  • 4.8w Per Metre
  • 60 x 3528 LED Chips Per Metre
  • 520nm Per Metre
  • Size: 8mm x 2mm
  • Cutting Increments: 50mm
  • Input voltage: 12v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 401

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • Green LED Strip
  • 3m Double Sided Tape For Easy Installation
  • 4.8w Per Metre
  • 60 x 3528 LED Chips Per Metre
  • 465nm Per Metre
  • Size: 8mm x 2mm
  • Cutting Increments: 50mm
  • Input voltage: 12v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 401

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • Red LED Strip
  • 3m Double Sided Tape For Easy Installation
  • 4.8w Per Metre
  • 60 x 3528 LED Chips Per Metre
  • 620nm Per Metre
  • Size: 8mm x 2mm
  • Cutting Increments: 50mm
  • Input voltage: 12v DC
  • IP rating: IP20
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 401

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 3000k LED strip
  • 3m double side tape for easy installation
  • 9.6w per metre
  • 120 x 3528 LED chips per metre
  • 780lm per metre
  • Size: 8mm x 3mm
  • Cutting increments: 25mm
  • Input voltage: 12v DC
  • IP rating: IP54
  • Maximum length: 5 metres
  • 3 Years replacement warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 381

Must be installed on aluminium heat dissipating surface for warranty purposes.

  • 4000k LED strip
  • 3m double side tape for easy installation
  • 9.6w per metre
  • 120 x 3528 LED chips per metre
  • 820lm per metre
  • Size: 8mm x 3mm
  • Cutting increments: 25mm
  • Input voltage: 12v DC
  • IP rating: IP54
  • Maximum length: 5 metres
  • 3 Years replacement warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 383

Must be installed on aluminium heat dissipating surface for warranty purposes.

  • 5500k LED strip
  • 3m double side tape for easy installation
  • 9.6w per metre
  • 120 x 3528 LED chips per metre
  • 860lm per metre
  • Size: 8mm x 3mm
  • Cutting increments: 25mm
  • Input voltage: 12v DC
  • IP rating: IP54
  • Maximum length: 5 metres
  • 3 Years replacement warranty (items ordered after 01/01/22)
  • 2022 Catalogue Pages 385

Must be installed on aluminium heat dissipating surface for warranty purposes.

  • 3000k LED Strip
  • 3m Double Sided Tape For Easy Installation
  • 19.2w Per Metre
  • 240 x 3528 LED Chips Per Metre
  • 1560lm Per Metre
  • Size: 10mm x 3mm
  • Cutting Increments: 25mm
  • Input voltage: 24v DC
  • IP rating: IP54
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 381

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 4000k LED Strip
  • 3m Double Sided Tape For Easy Installation
  • 19.2w Per Metre
  • 240 x 3528 LED Chips Per Metre
  • 1640lm Per Metre
  • Size: 10mm x 3mm
  • Cutting Increments: 25mm
  • Input voltage: 24v DC
  • IP rating: IP54
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 383

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 5500k LED Strip
  • 3m Double Sided Tape For Easy Installation
  • 19.2w Per Metre
  • 240 x 3528 LED Chips Per Metre
  • 1720lm Per Metre
  • Size: 10mm x 3mm
  • Cutting Increments: 25mm
  • Input voltage: 24v DC
  • IP rating: IP54
  • Maximum Length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Pages 385

Must Be Installed On Aluminium Heat Dissipating Surface For Warranty Purposes.

  • 3000k LED strip
  • 3m double side tape for easy installation
  • 4.8w per metre
  • 60 x 3528 LED chips per metre
  • 390lm per metre
  • Size: 8mm x 3mm
  • Cutting increments: 50mm
  • Input voltage: 12v DC
  • IP rating: IP54
  • Maximum length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 381

Must be installed on aluminium heat dissipating surface for warranty purposes.

  • 4000k LED strip
  • 3m double side tape for easy installation
  • 4.8w per metre
  • 60 x 3528 LED chips per metre
  • 410lm per metre
  • Size: 8mm x 3mm
  • Cutting increments: 50mm
  • Input voltage: 12v DC
  • IP rating: IP54
  • Maximum length: 5 metres
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
  • 2022 Catalogue Page 383

Must be installed on aluminium heat dissipating surface for warranty purposes.
